Frame holder two-way for posts made of round tube

제품 라인업 — Frames · Frame holders and Frame clamps

Frame holder two-way for posts made of round tube

No.	a	b	ø d1	ø d2	ø d3	kg
30917-0017-15	M6	25	17.2	33.7	13	0.0860
Further informations Weight: 0.0860 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-0026-15	M8	25	26.9	42.4	18	0.1770
Further informations Weight: 0.1770 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-0033-15	M8	25	33.7	42.4	18	0.1890
Further informations Weight: 0.1890 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-0042-15	M8	25	42.4	42.4	18	0.1960
Further informations Weight: 0.1960 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
