Frame holder two-way for posts made of flat profile or square tube

제품 라인업 — Frames · Frame holders and Frame clamps

Frame holder two-way for posts made of flat profile or square tube
No. a b c1 c2 ø d3 kg
30917-0020-14 M6 25 variabel / variable 20 13 0.0478
30917-0030-14 M8 25 variabel / variable 30 18 0.0960
30917-2040-14 M8 25 variabel / variable 40 18 0.1770
30917-2550-14 M8 25 variabel / variable 50 18 0.1770
30917-3060-14 M8 25 variabel / variable 60 18 0.1770
30917-4040-14 M8 25 variabel / variable 40 18 0.1770

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
