Frame holder two-way for frame type Inviss-C

제품 라인업 — Frames · Frame holders and Frame clamps

Frame holder two-way for frame type Inviss-C

No.	a	b	c2	ø d3	kg
30917-0020-20	M6	25	20	18	0.0500
Further informations Weight: 0.0500 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-0030-20	M8	25	30	18	0.1060
Further informations Weight: 0.1060 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-2040-20	M8	25	40	18	0.1130
Further informations Weight: 0.1130 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-2550-20	M8	25	50	18	0.1220
Further informations Weight: 0.1220 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-3060-20	M8	25	60	18	0.1300
Further informations Weight: 0.1300 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request
30917-4040-20	M8	25	40	18	0.1140
Further informations Weight: 0.1140 kg Material group: material group AISI 316L/1.4404 Price basis / tiered prices Price on request

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
